This is a Numatics filter/regulator/lubricator assembly. Please refer to the technical specifications in the listing for more information.
We have inspected this item and we do not have the capability to install the unit to fully test it. There are some cosmetic scuffs and scratches throughout the unit. Please refer to the photos for more information.
This unit only includes what is photographed in the listing.
Technical Specs
| Item | Filter/Regulator/Lubricator Assembly |
| Manufacturer Part Number | A652A0000019365 |
| Air Inlet Size | 1/4 in |
| Air Inlet Type | NPT |
| Maximum Flow Rate | 2,020 lpm |
| Maximum Operating Pressure | 10 bar |
| Filter Rating | 5 micron |
| Filter Bowl Capacity | 60 mL |
| Lubricator Bowl Capacity | 90 mL |
| Drain Type | Manual - Semi-automatic Drain |
| Overall Width | 7-13/16 in |
| Series | 652 |
| Filter Bowl Material | Aluminum |
| Lubricator Bowl Material | Aluminum |
| Lubricator Type | Mist |
| Adjustment Mechanism | Knob |
| Adjustment Mechanism Material | Plastic |
| Air Inlet Gender | Male |
| Air Outlet Gender | Male |
| Air Outlet Size | 1/4 in |
| Air Outlet Type | NPT |
| Body Material | Metal |
| Connection Style | Air Line |
| Drain Part Compatbility | M699AQ440512025 |
| Duty Rating | Intermediate Duty |
| Filter Element Material | Polyethylene - straining mesh |
| For Substance Type | Compressed Air |
| Maximum Operating Temperature | 50 °C |
| Minimum Flow Rate | 20 lpm |
| Minimum Operating Temperature | 5 °C |
| Number of Air Inlets | 1 |
| Number of Air Outlets | 1 |
| Overall Depth | 2-7/8 in |
| Pressure Control Type | Relieving |
| Pressure Gauge Port Gender | Male |
| Pressure Gauge Port Size | 1/4 in |
| Pressure Gauge Port Type | NPTF |
| Recommended Lubricant | VG32 - ISO3448 |
| Weight | 3.64 lb |
| Adjustment Location | Top |
| Air Flow Direction | Left to Right |
| Filter Type | Particulate |
| For Fluid Type | Compressed Air; Inert Gas |
| Overall Height | 10-11/16 in |
