This is an Aventics solenoid air control valve. Please refer to the technical specifications in the listing for more information.
We have inspected this item and we do not have the capability to fully test it. This unit needs to be hardwired and should be installed by a professional. There are some cosmetic scuffs and scratches throughout the unit. Please refer to the photos for more information.
This unit only includes what is photographed in the listing.
Technical Specs
| Item | Solenoid Air Control Valve |
| Manufacturer Part Number | L11XA452OP00030 |
| Pilot Type | Internal Pilot; Remote Pilot |
| Actuator Type | Single Solenoid |
| Flow Rate - Maximum | 46 cfm |
| Electrical Connection Type | Plug-In |
| Number of Ports | 5 |
| Return Action | Spring Return |
| Voltage | 110 to 120V AC |
| Override | Non-Locking |
| Series | L1, L1 |
| Number of Ways | Five-Way |
| Number of Positions | Two-Position |
| Operating Pressure - Minimum | 14 psi |
| Operating Pressure - Maximum | 150 psi |
| Operating Temperature - Minimum | -10 °F |
| Operating Temperature - Maximum | 115 °F |
| Inlet Port Connection Gender | Female |
| Inlet Port Connection Size | 1/8 in |
| Inlet Port Connection Type | NPT |
| Power Consumption | 4 W |
| Pilot Port Connection Size | 1/8 in |
| Pilot Port Connection Gender | Female |
| Pilot Port Connection Type | NPT |
| Application | Automotive; Bottling; Pressing; Stamping; Tire Manufacturing |
| Vacuum Rating | Vacuum Operable |
| NEMA Rating | 4 |
| Duty Cycle | Continuous |
| Body Material | Aluminum |
| Spool Material | Stainless Steel |
| Body Style | Base-Mounted; Inline |
| Pilot Pressure | 14.5 psi |
| Valve Type | Spool |
| Includes Mounting Hardware | Hardware Not Included |
| Coefficient of Volume (Cv) | 1 |
| Overall Height | 3-1/2 in |
| Overall Width | 1-1/2 in |
| Overall Length | 5-1/2 in |
| Standards | ANSI B.1.20.3 |
| For Media | Air; Inert Gas |
| Exhaust Port Connection Gender | Female |
| Exhaust Port Connection Size | 1/8 in |
| Exhaust Port Connection Type | NPT |
| Body Features | Single |
| Poppet Material | Aluminum |
